Fresh air dehumidifier

Dehumidifying fresh air fan

● Internationally renowned brand compressor: pure copper refrigerant tube, not easy to corrode, resistant to high pressure, and high compression efficiency.

● Branded DC motor: low energy consumption, high efficiency, stable operation and long service life.

● Strong drainage mode: automatically drains condensed water for safer use.

● Water full protection: When the water full signal is detected, the system will automatically stop working.

Covering air volume: 300~3000(m³/h)
Dehumidification capacity: 21~410(L/D)

Control switch

1. High-end intelligence: The entire series is equipped with 485 communication interface as standard, which is convenient for network control.

2. LCD control: Timed reminder for filter replacement.

3. Real-time display of temperature and humidity.

4. Timed start and stop function.

Dimensional drawings and table

Model	A	B	C	D	E	F	G	H	I	Φd1	Φd2	Φd3
DXF-20	345	597	300	644	698	140	193	244	399	110	75	100
DXF-30	403	703	360	751	890	170	224	275	454	150	100	150
DXF-50E	487	856	526	540	1042	224	407	409	599	150	150	200
DXF-80E	487	855	526	540	1023	224	407	409	599	250	150	250
DXF-150E	764	991	803	535	1158	320	494	496	853	310	200	310
DXF-300	940	1146	978	714	1280	453	581	585	1031	360x310	250	360x310

Product Parameters

Model	Power supply	Rated power (W)	Air volume (m³/h)	Dehumidification capacity (L/D)	Static pressure (Pa)	Fresh air volume (m³/h)	Noise dB(A)	Applicable area (m²) Floor height 2.8 meters	Weight (Kg)
DXF-20	220V/50Hz	265	200	14	40	0-70	40	15-35	22
DXF-30	220V/50Hz	380	300	21	50	0-100	43	30-60	30
DXF-50E	220V/50Hz	780	500	60	80	0-180	46	80-140	51
DXF-80E	220V/50Hz	980	800	80	100	0-250	48	100-180	54
DXF-150E	220V/50Hz	2500	1500	200	200	0-500	56	300-500	80
DXF-300	380V/50Hz	6000	3000	410	250	0-1000	60	600-1000	150
