Total heat exchanger

● Compact body: Smaller body, better sealing and easier installation.

● Selected Baosteel fingerprint-resistant steel plate: reliable quality, good mechanical properties, and elegant appearance.

● Patented heat exchange core: higher energy recovery efficiency. (Patent: 201910960256.X, 201720763607.4)

● High-efficiency motor: stable operation and strong power.

1. Indoor temperature display.

2. Three speed adjustment: low, medium and high.

3. Filter replacement reminder.

4. Built-in 485 communication interface.

5. Screen saver backlight, automatically turns off after 60 seconds.

model	Voltage (V)	Rated power (W)			Air volume (m³/h)			Static pressure (Pa)	Heat recovery rate (%) (when cooling)			Heat recovery rate (%) (heating)			Noise dB(A)			Weight (Kg)
model	Voltage (V)	high	middle	Low	high	middle	Low	Static pressure (Pa)	high	middle	Low	high	middle	Low	high	middle	Low	Weight (Kg)
AHE-15W1	220	80	68	55	150	120	75	60	60	64	67	65	68	71	32	29	26	21
AHE-25W1	220	160	103	70	250	175	125	80	60	64	68	65	68	71	36	29	26	31
AHE-35W1	220	180	105	70	350	280	180	80	60	64	68	65	68	71	36	29	26	35
AHE-50W1	220	340	210	145	500	350	250	110	60	64	68	65	68	71	39	31	28	44
